ATURES

l  Fashion, thin and well portable design;

l  Ultra low power design, over 3 hours continuous reading tag and over 1 day in standby;

l  Support interactive and trigger-activating work mode;

l  Support ISO18000-6C(EPC C1G2) protocol tag;

l  902~928MHz or 865~868MHz frequency band(frequency customization optional);

l  FHSS or Fix Frequency transmission;

l  Built-in TX/RX antenna with up to 50cm effective distance*;

l  RF output power from 0 to 26dbm (adjustable) with RSSI supported;

l  Multiple tag anti-collision>50pcs/s, multiple tag inventory speed>50pcs/s;

l  Tag buffer size: 370PCS@Max.128bitsEPC or 120PCS@Max.496bitsEPC;

l  Support Bluetooth 4.0. Built-in lithium battery and no external power supply needed;

l  USB1.1 interface. Provide DLL and demonstration software to facilitate development;

l  Support USB charging and also the charging indicator, the low battery indicator;

CHARACTERISTICS

l  Absolute Maximum Rating

l  Electrical Specification

* Effective distance depends on tag and working environment.

INTERFACE

1. Socket

Item	Description
Trigger Button	Activate the reader to read tag’s UID and send to host
Power Switch	Set left for power on and right for power off
Item	Description
Micro USB	Battery charging and USB virtual COM port

2. Panel Indicator

Item	Description
LED1	Red on during trigger-activating. Green flash when successfully reading a tag.
LED2	Red flash slowly shows the reader is power on.
LED3	Red on means low battery. Green on during battery charging.

Remark:

1. Specifications are subject to change, please pay attention to our latest version.

2. Our company reserves the right to the final interpretation of the above terms.
