Electrical Specifications
Frequency 902-928MHz/865-868MHz
Gain 4dBi
Beam width Hor：60°  Ver：60°
Polarization Circular
VSWR ≤1.4
F/B Ratio ≥20
Impedance 50Ω
Maximum power 50W
Lightning protection DC Ground
Connector N-Female
Mechanical Specifications
Dimension 165*165*20mm
Net weight 0.30kg
Packing size 40.5*30.5*10.5cm
Gross weight 1.35kg
Radome material ABS
Radome colour White
Operating temperature -40-70℃
