Electrical Specifications

Frequency

902-928MHz

Gain

9dBi

Beam width

Hor：70°  Ver：70°

Polarization

Circular

VSWR

≤1.4

F/B Ratio

≥20

Impedance

50Ω

Maximum power

50W

Lightning protection

DC Ground

Connector

N-Female

Mechanical Specifications

Dimension

258*258*42mm

Net weight

0.95kg

Packing size

40.5*30.5*10.5cm

Gross weight

1.95kg

Radome material

ABS

Radome colour

White

Pole Diameter

Φ40-60mm

Rated wind velocity

60m/s

Operating temperature

-40-70℃
