Product parameters
Performance
Octa core
CPU Cortex-A53 Octa-core 64-bit 2.0GHz
high-performance processor
RAM+ROM 3GB+32GB
Supports up to 4GB+64GB
Expand memory Micro SD(TF) Supports up to 128GB
System Android 9.0
Data communication
WLAN Dual-band 2.4GHz /5GHz,
Supporting IEEE 802 a/b/g/n/ac protocol
WWAN 2G：GSM（850/900/1800/1900mhz）
 3G：WCDMA（850/900/1900/2100mhz）
 4G：FDD:B1/B3/B4/B7/B8/B12/B20
     TDD:B38/B39/B40/B41
Bluetooth Support Bluetooth 2.1+EDR/3.0+HS/4.1+HS
Transmission distance 5-10 meters
GNSS Support Gps, Galileo, Glonass, Beidou
Physical parameter
Dimensions 159mm×75mm×124mm
Weight ＜500g
(Depends on device function configuration）
Display 5.7 inch IPS color display with resolution720*1440
TP Corning gorilla glass, Supports multi-touch
Supported gloves and wethands
Battery capacity Rechargeable polymer battery (3.8V 5000MAh) removable
 Standby time >350 hours
 Working time > 12 hours
 Charging time 3-4H, Using standard power
adapter and data cable
Expansion
Card slot PSAM x 2, Nano SIM card x 1 , TF card × 1
Communication interface Type-C USB x 1, OTG
Audio Speaker (mono), Microphone, Earpiece
Keypad Power button, Volume +/- button,Scan button × 2
Handle scan button ×1
Sensors Gravity sensor, Light sensor, Proximity sensor,
Vibration motor

Data collection
Barcode scanning(Optional)
2D Imager scanner Honeywell N3603
2D
Symbologies PDF417,Micro PDF417,GS1 Composite,Aztec Code,Data Matrix,QR Code,Micro QR Code,
Maxicode,Hanxin Code,etc.
UHF
Engine Engine CM2000-1, based on Impinj Indy R2000
Frequency(CHN) 920-925MHz
Frequency(USA) 902-928MHz
Frequency(EHR) 865-868MHz（ETSI EN 302 208）
Frequency(Other) Other multinational frequency standards (can be customized)
Protocol EPC C1 GEN2 / ISO18000-6C/6B
Antenna Circularly polarized antenna (4dBi)
Power 30dBm, support +5dBm ~ +30dBm adjustment
Distance 0-6m
Reading speed >200 tags per second (circular polarization)
Note:*Card reading distance and group reading rate are related to the actual environment
Camera
Rear camera 13MP HD camera,Support auto focus,
Flash, Anti-shake, Macro shooting
Front camera 2MP color camera
NFC(optional)
Frequency 13.56MHz
Protocol Support ISO14443A/B, 15693 agreement
Distance 2cm-5cm
Language/input method
Input English, Pinyin, Five strokes, Handwriting input, Support soft keypad
Language Language packs in Simplifie Chinese,
Traditional Chinese, English, Korean, Japanese, Malaysian,etc.
User environment
Operating temperature -20℃ - 55℃
Storage temperature -40℃ - 70℃
Environment humidity 5%RH--95%RH(no condensation)
Drop specification 6 sides Supports 1.2 meters drops and 30 times
to the concrete within the operating temperature
Rolling test 500×0.5m rolling for 6 sides
Sealing IP66
Accessories
Standard Adapter, Data cable, Protective film,
Instruction manual
