Performance

Model

ZK-RFID9171A

O.S.

Android 9.0

Processor

Octa-core 1.4GHz

Memory

RAM： 2GB ROM： 16GB

RAM： 4GB ROM： 64GB (optional)

Extended memory

Micro-SD card, up to 128 GB

Basic specifica tions

Dimensions

143.3mm X 169mmX90.5mm

Weight

678g

Display

5.7 inch HD display, 720X1440 resolution.

Touch Screen

Ultra-sensitive capacitive touch panel ,works with gloves and wet fingers ;Corning Gorilla Glass 3; 5 fingers Multi-touch

Main battery

Capacity： 3.85V 9000mAh

Charging time

<7 hours

Audio

Speakers、Dual Microphones、Earphone、Receiver

Buttons

Volume+/-x Power, Scan buttonX2, Programable button, Pistol Grip trigger button

Camera

Front5MPixels, Rear 13MP auto-focus color rear camera with flash

Sensors

Light + Accelerator+ Proximity + Geomagnetic + Gyro (optional)

Scanning

1D/2D barcode reader

Can read all international standardslD/2D barcode；

Can read barcode displayed on screens and colored barcode；

Slots

MicroSD/TFxl, Nano-SIMx2

Wireless commu nication

WAN

Dual-SIM, Dual-Standby

4G,3G,2G

Bluetooth

BT4.2+BR/EDR+BLE

Wi-Fi

2-4G/5G, IEEE802.11a/b/g/n/ac/d/e/h/i/k/r/v/w

Roaming： 802.Hr/OKC/ PMKID caching

Positioning

GPS, A-GPS, BEIDOU, GLONASS、Galileo

Environ

merit

Temperature

-20°C 〜+60°C

Storage

-40°C 〜+70°C

Humidity

5%RH〜95%RH (No condensation)

Drop test

1.2 meters

Tumbling

4003.2ft./1.0mtumbles

Exceeds MIL-STD810G

Seal

IP65

Camera

Rear Camera

1300W

Front Camera

500W

Focus method

Auto focus, touch selection, face detection

flash

700mA, support flashlight function

Video

1080p front and rear camera video recording

Module

2D Barcode

Scan Angels Tilt

360°

Scan Angels Pitch

±45°

Scan Angels Skew

±60°

Laser type

Class Ⅱ

Barcodes support

UPC/EAN, UPC/EAN with supplementals, Code128, GS1-128, Code 39, Trioptic, Code 32, Code 93, Code11, Matrix 2 of 5, Interleaved 2 of 5, IATA 2 of 5, Industrial 2 of 5,Codabar, Codablock F,MSI,Telepen,Code11, GS1 DataBar variants,PDF417, MicroPDF417, Composite Code,Data Matrix, Maxicode, QR Code, MicroQR, Aztec

RFID

UHF

Frequency

865-868MHz,902-928MHz

Protocol

ISO 18000-6C(EPC Global Class 1 Gen 2)

ISO 18000-6B

Reading Distance

up to 7 meters(relative to tags)

Antenna gain

Gain 4.5dBi

Positioning

Specification

Support

GPS、A-GPSx BEIDOUx GLONASS、Galileo

Frequency

GPS(L1 1.575GHz C/A code), BEIDOU (Bl 1.561GHz),GLONASS(L1 1.602GHz), Galileo (El 1.589 GHz/E2 1.561 GHz)

Cold start

Less than 40s

Channels

Max31channels

Sensitivity

-130dB

Precision

5-10 Meters (open space)

WIFI

Specification

Protocol

IEEE802.11a/b/g/n/ac/d/e/h/i/k/r/v/w (2.4G/5GWi-Fi)

Frequency

2.4G/5G

Working Channels

2.4G： CH1-CH13 (Depends on Country/Region)

5G：

36/38/40/42/44/46/48/52/56/60/64/100/104/108/112/116/120/124/128/132/1

36/140/149/153/157/161/165 (Depends on Country/Region)

Security

EAP-TLS, EAP-TTLS, PEAP-MSCHAPv2, PEAP-TLS, PEAP-GTC, PWD, SIM,

AKA, WEP , WPA/WPA2-PSK, WAPI certificate, WAPI-PSK

Roaming

Support PMKID caching, 802.Hr, OKC

WAN

Specification

Mode

Dual-SIM, Dual-Standby

Global Version

4G(TD-LTE)

4G(FDD-LTE)

TD-LTE:B34/B38/B39/B40/B41

FDD-LTE(B1/B2/B3/B4/B5/B7/B8/B12/B13/B17/

B19/B20/B25/B26/B28A/B28B/B66

3G(WCDMA)

3G(CDMA2000)

3G(TD-SCDMA)

WCDMA: B1/B2/B4/B5/B8

TD-SCDMA(B34/B39)

CDMA2000 lx EV-DO Rev-A BC0 (800MHz)

2G

CDMAlx

GSM/EDGE/GPRS(850/900/1800/1900)

Bluetooth

Specification

Support

BT4.2+BR/EDR+BLE

Distance connect

>10 m

Accessories

Specification

Accessories

Dock charger (supports 1 device + 1 battery charging), five-row charger, tempered film
